TallyGenicom 6800

The TallyGenicom 6800 printers offer

    A better price-performance ratio, improved efficiency and lower operating cost thanks to its next-generation line matrix printing technology The TallyGenicom 6800 cartridge printers offer new design and better functionality for broader flexibility, greater compatibility, and the lower ownership costs of any line matrix printer. This series of printers is based on the workhorse tradition of the TallyGenicom line matrix technology and positions the 6800 cartridge printers as the perfect solution when you need a flexible design, adaptable functionality and savings management. These printers offer maximum operational activity time, lower property costs, small dimensions and a reduced noise level.
COMPATIBILTY
The 6800 cartridge printers are designed to offer businesses an easy route to modernizing TallyGenicom 6200/6300 printers or Printronix P5000 line matrix  printers or other brand dot matrix printers. It is the ideal solution for companies that are concerned about the high cost of technology and that should choose an industrial printing technology that offers high reliability even working in environments with extreme operating conditions such as cold, heat or dirt and in limited spaces. .
APLICATIONS
This family of printers provides the widest flexibility, the highest compatibility and the lowest cost of ownership of any line matrix printer available in the market. The TallyGenicom 6800 printers are ideal for manufacturing, distribution and logistics companies, governments, banking and the automotive sector ; places where it is necessary to print invoices, referrals, documentation of shipping and transportation of products, bank account statements, reports and product compliance labels. Perfect substitute for matrix models with character technology per second models: DFX5000 DFX8000 DFX 8500 DFX9000 oki 4410 as well as  discontinued versions of IBM 6400 & Infoprint 6500 Printronix P5000 TallyGenicom 6200 and 6300 3 versions available

TallyGenicom 6800



CONNECTIVITY / INTERFACES

Parallel optional USB 2.0 standard, RS-232 serial, Ethernet 10 / 100BaseT – IEEE 1284 Centronics

CHARACTER PITCH (characters per inch)

5, 6, 6.7, 7.5, 8.3, 8.6, 10, 12, 13.3, 15, 16.7, 17.1, 20

LINE SPACE (lines per inch)

1,5, 2, 3, 4, 5, 6, 8, 9, 19, 12

Graphic resolution

240 dpi horizontal, 288 dpi vertical (max)

POINT SIZE

16.7 mil (.42mm)

Emulations

Tally ANSI standard, Genicom ANSI, P5000 / P600 / P6000, Epson FX-1180, IBM Proprinter, MTPL (Point matrix Tally), PGL (TG version), QMS Code V, Tally Industrial Graphics, PCL3, HP-2564C, / DEC LG01

Character sets

47 languages ​​and 43 character sets

STYLES OF CHARACTERS

Bold, italics, superscript, subscript, underline, underline, strikethrough

SOURCES

Draft, Data Processing, Courier, Gothic, OCR-A and B

BAR CODES

Code 39, Code 128, Interleaved 2 of 5, UPC-A, UPC-E, EAN 13, EAN 128, Codobar, MSI, PDF-417, Postnet, Smart Mail Barcode (IMB)

Printer software

Remote management software PrintNet Enterprise

PRINTER DRIVERS

Windows XP, 7, 8, 10; Windows Server 2003, 2008 / R2, 2012

POWER TENSION

Input range of AC 100-240 VAC, 50/60 HZ

ENERGY CONSUMPTION (typical)

  • • P6805 / C6805 / Z6805 320 Watt
    • P6810 / C6810 / Z6810 320 Watt
    • C6815 475 Watt
    • C6820 475 Watt

ENERGY CONSUMPTION (On hold)

Less than 5 watts

OPERATING TEMPERATURE

Operating ambient temperature 50 ° to 104 ° F, 10 ° to 40 ° C

KIND OF PAPER

Continuous, fan, perforated on the edges.

PRINTING WIDTH

13.6 “(345mm)

Copies of media

Up to 6 parts; Up to 4 parts for Zero Tear models.

MEDIA LENGTH

3 “(76 mm) to 12” (305 mm)

HALF THICKNESS MULTIPARTE

0.025 “(0.64mm) max

MEDIA WIDTH

  • 3 “(76 mm) to 17” (432 mm)
  • For Zero Tear models:
  • For Zero Tear models:
  • 7.5 “(191 mm) to 12” (305 mm) for up to 4 parts of carbon and 6 parts without carbon
  • 7.5 “(191 mm) to 16” (406 mm) for up to 3 parts of carbon and 4 parts without carbon

HALF WEIGHT ONLY MORE

  • 15 lb. link to 100 lb. (56 to 163 g / M2)
  • For Zero Tear models:
  • 18 lb. Bond 100 lb. label (67.7 to 163 gm / M2) for shapes up to 12 “(305 mm) wide
  • 20 lb. Bond 100 lb. label (75.2 to 163gm / M2) for shapes up to 16 “(406 mm) wide

MTBF
10,000 hours at 25% duty cycle and 25% page density

CONSUMABLE / TAPES

  • Standard life cartridge tape 17,000 pages
  • Long life cartridge 30,000 pages
  • Page performance based on ISO LSA page, letter size 8.5 “x 11”, approximately 5% coverage
