Printronix P7000

DISCONTINUED MODEL REPLACED BY THE PRINTRONIX P8000 MODEL

Despite its huge success in the international market, Printronix has decided to replace the Printronix P7000 line of dot-matrix printers with the new P8000 series, offering cost and feature improvements as well as a wider variety of models. , such as the office model. missing in the p7000 series

In spite of that MPI, continues to provide in the possible way its service of support, telephone assistance (in Spanish, French or English), as well as the supply of spare parts and consumables.

However, we have decided for the moment to leave the technical information of the product on our page.

RESISTANT, PROFITABLE AND VERSATILE

The P7000 printronix offers unparalleled reliability when its production must not be interrupted. The models in the Printronix P7000 series are: P7005 P7205 P7010 P7210 P7015 P7215 P7220.

For cost control, this technology is the necessary weapon because it offers the lowest cost per page. 500 to 2000 lines per minute models with soundproof booth or multiple pedestal emulations for graphics and barcodes: IPDS - IGP / Printronix Graphic Languge / VGL.

PRINTRONIX P7000 IMPROVED RELIABILITY

No other printing technology provides a larger print volume than Printronix line printers.
Each of our printer generations offers higher quality and reliability than its predecessor. Now the P7000 series, with a wide
range of design enhancements, continues the tradition and presents the most reliable Printronix printer in its history. This results in increased availability, increased
reliability in critical situations, and reduced operating and maintenance costs.

Perfect substitute for DFX5000 DFX8000 DFX 8500, DFX9000 oki 4410 DFX5000 as well as discontinued versions of IBM 6400 Infoprint 6500 Printronix p5000 TallyGenicom 6200 and 6300

Print speed (LPM, uppercase characters, lowercase characters)

MODELS P7205 P7005 P7210 P7010 P7215 P7015 P7220

High speed 500/428 1000/856 1500/1289 2000/1700
Data processing 375/300 750/600 1125/900 1500/1200
Quality next to the letter 200/154 400/306 600/459 800/615

Graphic Speed (IPM)
60 x 48 dpi 63 125 187 250
60 x 72 dpi 42 83 127 167
90 x 96 dpi 21 42 61 83
Paper Feed Speed 12 20 25 38.5 (PPS)

PRINT GENERAL

Print Method Impact Line Matrix
Character Fonts High speed, data processing, near letter quality
Character spacing 10, 12, 13.3, 15, 17.1, 20 (inches per inch) (except for NLQ for spacing 20)
Separation between lines 6, 8, 10.3, n / 72, n / 216 (lines per inch)
Maximum resolution 180 dpi horizontal, 144 vertical dpi
Printable width up to 13.6 “(345.4 mm)

COMPATIBILITY

Printronix P Series, P Series XQ Series Emulations, Serial Matrix, IBM ProPrinter III XL, Epson FX-1050

Optional PGL / VGL, ANSI 3.64, IPDS (twisted pair and Ethernet), TN5250, TN3270, PCL 2, DEC LG, twisted pair, coaxial and twisted pair emulations – IBM 5225 Models 1, 2, 3, 4, IBM 4234 Model 2 , 12, transparent Printronix mode available for special functions.
Coax – IBM Model 3287 1 and 2, Model 4234 IBM, BSC, SCS / LU1, DSC and DSE compatible modes. Transparent Printronix mode available for special functions.

Dynamic font selection Selectable print style: Bold, Italic, Double Width, Double Height, Highlight, Underline, Index and Exponent. It offers a wide combination of fonts.

Unicode UTF-8 resident character sets and more than 100 multinational games, including IBM World Trade, ECMA Latin
100, Multinational DEC, IBM Code Page 437 and 850, OCR A, OCRB

NLQ serif sources, NLQ Serifless, data processing, high speed, OCR A, OCR B
Resident bar codes 30 resident codes: Code 39, EAN 8/13, UPC A / E, Postnet, Royal Mail, 2 interleaved out of 5 and PDF 417

PAPER MANAGEMENT

Continuous type, accordion, with perforated edges
Width 3 “to 17” Copies Up to 6 pieces
Weight 15 to 100 pounds, up to 0.025 “Stroke of
paper Direct with dual adjustment tractors for easy loading
Food Lower feeding

PRINTER SOFTWARE AND DRIVERS

Printronix PrintNet Enterprise Remote Management Software
Types of SAP Devices Windows 95/98 / NT / 2000 / XP

ORIGINAL PRINTRONIX BANDS

Ultra Capacity The darkest and most durable band for
barcode, OCR and text applications, with a capacity of 90 million characters.
Label For applications using glossy or coated label material, 65 million character capacity.

INTERFACE

RS-232 Serial (RS-422 Optional) Parallel IEEE-1284 / Centronics (Standard) Data Products (Optional) Ethernet PrintNet Enterprise 10/100 Base T (Optional)
802.11b Wireless Ethernet (Optional) Wireless Radios compatible wire (not included) Lucent ™ (Proxim) Cisco ™ Orinoco AIR-LMC352 (MMCX Connectors)
Twinax twisted pair (twisted pair) integrated interface for connection to IBM 36/38 and AS / 400 systems, directly or through the controller IBM 5394 or 5494 Workstation (Optional) Coaxial Integrated Coaxial Interface for Connection to IBM Group Controller 3174, 3274, or 3276 (Optional) Automatic Switching Between Active Ports

POWER SUPPLY P7X05 P7X10 P7X15 P7220

Typical Watts 175 260 390 475
Line (+/- 10%) 100-120 VAC Auto Adjustment, 200-240 VAC, 50/60 Hz
Energy Star Compliance – Less than 28 Watt (Power Saving Mode)

DIMENSIONS

Base Cab with SureStak Height 3614 (914mm) 1041mm 41 “(1041mm) 41” (660mm) 26 “(686mm) 27” (686mm) Depth 21 “(533mm) 29” (737mm) 33 “(838mm)
Weight with packaging 170 pounds (77.2 kg) 275 pounds (124.8 kg) 305 pounds (138.4 kg)

ENVIRONMENT

Sound level P7005 – 62 dBA P7205 – 50 dBA (according to ISO 7779) P7010 – 65 dBA P7210 – 50 dBA P7015 – 68 dBA P7215 – 52 dBA
P7220 – 55 dBA
Paper control 14 and 12 channel vertical format electronic unit, detector and Paper Output, Sensor and Paper Motion Sensor
Operating Temperature 50 ° C to 104 ° F from 10 ° C to 40 ° C
