Printronix T8000

Printronix-T8000

Printronix-T8000

printronix T8000The Printronix T8000 is the premier high-end thermal printer.





With unmatched industrial performance, easy to use, and 100% verifiable output, the Printronix T8000 exceeds the requirements of the most demanding mission critical manufacturing and distribution operations.



  • PRINTRONIX T8000 EASY-TO-USE

New 3.4” full color display panel with easy to use navigation keys Most extensive library of print emulations in the industry, now includes Postscript/PDF printing Intuitive printer setup, print quality,and self-help wizard Easily accessible side media loading Quick Change Memory Card stores printer configuration and network settings for easy installation of new printers

  • INDUSTRIAL PERFORMANCE

Seamless integration & connectivity with robust remote printer management 40% faster print speed, 6x faster processing speed, and 8x more memory than the competition Rugged design for the most demanding global customers and the harshest environments Energy Star compliant

  • VERIFIABLE OUTPUT

Eliminate compliance fines and chargebacks with Online Data Validator (ODV) to produce 100% scannable barcodes every time Automatic capture of statistics that can be used as certification stamp and audit Fully integrated solution with the ability to retract, void, and reprint labels automatically.



Printronix T8000 Rugged design with industry leading capabilities to print PostScript/PDF, print in sub-zero temperatures without eated enclosures, all while remotely managing your environments with PrintNet Enterprise.



  • CONNECTIVITY ANYWHERE

Experience unrestrained networking power anywhere on your premises Increase productivity by printing labels and barcodes at points of need Various connectivity options available with latest wireless security protocols Robust networking capabilities and support for both 2.4 GHz and 5.0 GHz frequency bands Hi-res, icon-based color panel displays instant and easily visible printer status  Availability of industrial PrintCart, to extend mobility and connectivity

  • POSTSCRIPT/PDF

First to offer Postscript/PDF for thermal printing Seamless connectivity of PostScript/PDF files for quick deployment Supports the latest ERP systems, and Plug-n-Play with native SAP Drivers

  • HARSH ENVIRONMENT

Reliable performance in sub-zero environments without a heated enclosure. -5C for direct thermal and 5C for thermal transfer Cold supply chain customers can realize cost savings on heated enclosures and energy consumption Ability to handle dirt, grime, humidity, and extreme temperatures found in manufacturing, warehouse, and distribution centers around the globe

  • PRINTNET ENTERPRISE

Robust remote printer management to monitor printers and virtual control panel to configure from anywhere in the world Designate events and be alerted of printer issues via email, pager or mobile phone alerts Complete compatibility with any Printronix Auto ID product



OPTIONS AND ACCESSORIES PRINTRONIX T8000

  • WiFi 802.11 a/b/g/n
  • Rewind with Peel & Present 4”/6”/8”
  • Parallel Port Card
  • Heavy Duty Cutter 4”/6”/8”
  • GPIO
  • TN5250
  • Premium Asian Font Cards
  • PostScript/PDF
  • Premium Andale Font Cards
  • IPDS
  • QCMC (SD Quick Change Memory Card)
  • Online Data Validator (ODV)



Link Printronix WEB: http://printronixautoid.com/t8000/

PRODUCT BENEFITS PRINTRONIX T8000

  • High performance ARM Cortex-A9
  • Available in 203 DPI and 300 DPI
  • 4”, 6”, and 8” model configurations
  • Die-cast aluminum frame w/metal doors
  • Dual motor ribbon drive system
  • Transfer and direct printing
  • State-of-the-art WiFi Connectivity
  • 512MB RAM / 128 Flash Memory
  • 4-32 GB SD flash memory card capability
  • Premium Asian and Andale font support
  • ENERGY STAR Certified. Printronix Auto ID is proud to offer our customers products that have earned the government’s ENERGY STAR label

PRINTER SPECIFICATIONS

  • Max Print Speed (4”/6”/8”): 14/12/10 IPS @ 203 DPI 12/10/8/ IPS @300 DPI
  • Print Method: Transfer and Direct
  • Resolution: 203 DPI or 300 DPI
  • Max. Print Width: 4.1” (104mm)/6.6” (168mm)/8.5” (216mm)
  • Printer Memory: 512MB RAM / 128MB Flash

MEDIA SPECIFICATIONS

  • Media Type: Roll or Fan-Fold Labels, Tags, Paper, Film, Tickets
  • Min. Media Width: (4”/6”/8”): 1” (25.4mm)/2” (50.8mm)/3” (76.2mm)
  • Max. Media Width: 4.5” (114.3mm)/6.8” (172.7mm)/8.75” (222.2mm)
  • Min. Media Length: 0.25” / 1.0” (Continuous/Tear-Off)/0.5” (Peel-Off)
  • Max. Media Length: Up to 99” (251.46cm)
  • Media Thickness: 0.0635mm (0.0025”) to 0.254mm (0.010”)
  • Media Roll Core Diameter: 1.5” (37.5mm) to 3.0” (76mm)
  • Max. Media Roll Diameter: 8.0” (209mm)
  • Media Sensing: Gap, Mark, Advanced Gap, Advanced Notch

RIBBON SPECIFICATIONS

  • Ribbon Type: Wax, Wax/Resin, Resin
  • Min. Ribbon Width: (4”/6”/8”) 1” (25.4mm)/2” (50.8mm)/3” (76.2mm)
  • Max. Ribbon Width: (4”/6”/8”) 4.5” (114.3mm)/6.8” (172.7mm)/8.75” (222.2mm)
  • Max. Ribbon Length: 625 Meters

PHYSICAL CHARACTERISTICS

  • Width (4″/6″/8″): 11.7″ (297.2mm) / 13.4″ (340.4mm) / 15.4″ (391.2mm)
  • Height (4″/6″/8″): 13″ (330.2mm) / 13″ (330.2mm) / 13″ (330.2mm)
  • Depth (4″/6″/8″): 20.5″ (520.7mm) /20.5″ (520.7mm) / 20.5″ (520.7mm)
  • Printer Weight (4″/6″/8″): 37 lbs. (16.7Kg.) / 40 lbs. (18.1 Kg.) / 43 lbs. (19.5Kg.)
  • Shipping Weight (4″/6″/8″): 46 lbs. (20.8Kg.) / 49 lbs. (22.2 Kg.) / 52 lbs. (23.6Kg.)

PROGRAMMING PRINTER LANGUAGES

  • IGP Languages: PGL/VGL/ZGL/TGL/IGL/STGL/DGL/IEGL/MGL
  • Line Printer Plus Languages: P-Series + XQ, Proprinter, Serial Matrix, Epson
  • Job Control Languages: PJL, XML, and PTX-SETUP
  • Optional Languages: IPDS, TN5250/TN3270, PDF Level 1.7, Postscript Level 3

COMMUNICATION AND CONNECTIVITY/INTERFACE

  • Standard Interface I/O: Serial RS232, USB, and Ethernet 10/100Base T
  • Optional Interface I/O: Parallel, WiFi (802.11a/b/g/n), GPIO
  • WiFi Security Protocol: WEP 40/128bit, WPA Personal (TKIP), WPA2 Personal (AES/CCMP), EAP-PEAP, EAP-TTLS, PEAPv0/EAP-MSCHAPv2, EAP-TLS

BARCODE VALIDATION PRINTRONIX T8000

  • Online Data Validator (ODV) – Validates, Grade, Report, and Overstrike barcodes Supports 1D Barcodes

MEDIA HANDLING MODES

  • Standard: Continuous, Tear-Off Strip, Tear-Off
  • Options: Peel-Off, Cut, and Rewind

OPERATING ENVIRONMENT

  • Operating Temperature (Direct Thermal w/o accessories): 23 to 104 F (-5 to 40 C)
  • Operating Temperature (Thermal Transfer or Direct Thermal w/ accessories): 40 to 104 F (5 to 40 C)
  • Operating Humidity Range: 20 to 85% Non-Condensing
  • Storage Temperature: -23 to 140 deg. F, (-5 to 60 deg. C)
  • Storage Humidity Range: 5% to 85% Non-condensing

POWER REQUIREMENT

  • Line Input: Auto Range 90 – 264 VAC (48 – 62 Hz)

REGULATORY COMPLIANCES

  • Emissions: FCC, CE, CCC
  • Safety: cTUVus, CE, EAC, SABS, RCM, CCC, KCC, BSMI, S-MARK, NOM
  • Environmental: RoHS, WEEE, Energy Star

BARCODE SYMBOLOGIES

  • 1D Barcodes: BC-412, Code 11, Code 39, Code 35, Code 93, Codabar, Code128 Subsets A/B/C, Industrial 2 of 5, Interleave 2 of 5, German I-2/5, EAN-8, EAN-13, UCC/EAN-128, UPC-A, UPC-E, UPCSHIP, UPS 11, MSI, Matrix 2 of 5, PLESSEY, POSTNET, 4-state PostBar, Australian 4-state, FIM, ITF14, TELEPEN, PLANET, USPS Intelligent Mail, LOGMARS
  • 2D Barcodes: PDF-417, MicroPDF-417, Maxicode, DataMatrix, QR Codes, Aztec, GS1 Databar (RSS-14)

FONT, GRAPHIC SUPPORT

  • Graphic Formats: PCX, TIFF, BMP, PNG
  • Font Technologies: Intellifont, TrueType, Unicode
  • Standard Fonts: OCRA, OCRB, Courier, Letter Gothic, CG Times, CG Triumvirate/Bold/Condensed
  • Asian Fonts (Optional SD card): Simplified Chinese, Japanese, and Korean
  • Andale Fonts (Optional SD card): Simplified Chinese, Traditional Chinese, Korean, Japanese
  • PDF/ PostScript Level 3: 35 Fonts

REMOTE MANAGEMENT SOFTWARE

  • PrintNet Enterprise Suite: Enterprise grade remove management solution
