Printronix T4000

Printronix S828 T4000

NEW PRINTRONIX T4000 THERMAL PRINTER





Small, fast and ready to optimize productivity The T4000 is our most compact and affordable industrial printer, with the capacity to print 5000 labels per day at speeds of up to 8 inches per second. If you aspire to improve productivity ... look no further. The T4000 includes the Printronix System Architecture platform (Printronix system architecture [PSA]), with multiple connectivity options, tools for remote management of printers and automated alerts to keep your business running at optimal levels of efficiency and productivity.



BUSINESS LEVEL PRODUCTIVITY

  • Industry-leading print speed, 8 ips
  • Easily print 5,000 labels a day in demanding environments
  • Compatible with PrintNet Enterprise, tool for managing printers
  • ARM Cortex A-7 fast processor
  • Thanks to automatic alerts, your company remains efficient and productive
  • Maximization of production time thanks to the compatibility with 8 "rolls for labels and with 450 m tapes



ADAPTABLE FEATURES PRINTRONIX T4000

  • Wide standard connectivity: Ethernet, USB host, USB device, serial
  • Optional connectivity: Enterprise-level WiFi: 802.11 a / b / g / n / ac, Bluetooth 4.2
  • Security and encryption protocols for enterprise-level WiFi
  • 9 printer emulations to achieve seamless integration
  • Due to its compact size, it is ideal for many sectors



RELIABLE DESIGN

  • Heavy-duty metal housing with foldable side panel
  • Created with the Printronix System Architecture (PSA) platform for assured reliability
  • Patented printhead algorithms produce high quality barcodes
  • Large color LCD screen and easy-to-use control panel
  • Great MTBF of up to 12,000 hours
  • Wide spectrum of operating temperature from 0 ° C to 40 ° C

LINK MANUFACTURER:  http://printronixautoid.com/products/industrial-printers/t4000/





PRINTRONIX T4000

  • ARM Cortex-A7 high performance
  • 128 MB of RAM / 128 MB of flash memory
  •  System architecture Printronix (PSA)
  • Nine-button LCD 3.5-inch color control panel
  •  Four inch print width
  •  203 dpi or 300 dpi
  • SD memory card capacity of 4-32 GB
  • Asian Andale and Premium fonts (optional)
  • Transfer and direct printing
  • Ethernet 10/100 BaseT (Standard)
  • ENERGY STAR certification
  • Enclosure of steel frame
  • Bifold media door
  • WiFi 802.11 a / b / g / n / ac (optional)
  • Bluetooth 4.2 (optional)

CHARACTERISTICS OF THE PRINTER

  • Max. Print speed 8 IPS @ 203 DPI, 6IPS @ 300 DPI
  • Direct and transfer printing method
  • Resolution 203 DPI / 300 DPI
  • Max. Print width 4.1 "(104 mm)

MEDIA SPECIFICATIONS

  • Type of media Labels on roll or folded fan, Labels, Paper, Film, Min.
  • Media width 1.0 "(25.4mm)
  • Max. Paper width 4.72 "(120mm)
  • Min. Continuous media length 0.25 ", stripping / detachment 1.0"
  • Max. Medium length up to 50 "
  • Media thickness from 0.00236 "(0.06 mm) to 0.011" (0.279 mm)
  • Diameter of the media roll core 3.0 "(76.2 mm)
  • Max. Diameter of media roll 8.0 "(203mm)
  • Media Sensing Gap, Mark

CHARACTERISTICS OF THE TAPE

  • Type of wax tape, wax / resin, resin
  • Min. Tape Width 1.6 "(40mm)
  • Max. Tape Width 4.33 "(110mm)
  • Max. Length of the tape 450 meters
  • Diameter of the core of the tape 1.0in

PHYSICAL CHARACTERISTICS

  • Width 10.4 "(264mm)
  • Height 10.9 "(276mm)
  • Depth 17.9 "(455mm)
  • Printer weight 22 lbs (10kg)
  • Shipping Weight 28 lbs (13Kg)

PRINTER EMULATIONS PRINTRONIX T4000

  • Printer languages: (Native / Competitor) PGL / ZGL / TGL / IGL / STGL / DGL / IEGL / MGL / EGL
  • API's: XML
  • Emulations of printers of inherited lines: VGL (Code V), P-Series / XQ, Epson FX, Serial Matrix, Proprinter
  • Work control languages: PJL, PTX-SETUP

COMMUNICATION AND CONNECTIVITY / INTERFACE

  • Standard interface I / O: RS232 series, USB device (type B), USB host (type A) and Ethernet 10 / 100Base T
  • Optional I / O interface: WiFi (802.11a / b / g / n / ac), (WiFi Alliance Certified) Bluetooth 4.2
  • WiFi security protocol: WEP 40 / 128bit, TKIP, AES CCMP
  • WiFi Security Authentication: WPA / WPA2 PSK, EAP-TTLS, EAP-PEAP, LEAP, PEAPv1 / PEAP-TLS, PEAPv0 / MS-CHAPv2

MEDIA MANAGEMENT MODES

  • Standard: Continuous, Tear-Off
  • Options: Peel / Rewind (paper labels, 6 tips, rewind the liner of an 8-inch roll) Cutter (thickness according to paper specifications, useful life of 500,000 cuts)

OPERATIONAL ENVIRONMENT

  • Operating temperature: 32 to 104 ° F (0 to 40 ° C)
  • Operating humidity: 25 - 85% non-condensing
  • Storage temperature: -40 to 140 ° F (-40 to + 60 ° C)
  • Storage humidity: 10 - 90% non-condensing

POWER REQUIREMENTS

  • Auto Range 100 - 240 VAC (48 - 62 Hz)

NORMATIVE COMPLIANCE

  • Emissions: FCC, CE, IC, CCC, KC
  • Security: cTUVus, CE, IC, EAC, S-MARK, NOM, CCC, KC, BIS, BSMI
  • Environmental: RoHS, WEEE, Energy Star
  • WiFi / BT: FFC, IC, CE, CCC
  • Energy saving: Energy Star 2.0

BAR CODE SYMBOLS

  • 1D Barcodes: BC-412, Code 11, Code 39, Code 35, Code 93, Codabar, Subsets Code 128 A / B / C, Industrial 2 of 5, Interleaved 2 of 5, German 1-2 / 5, EAN -8, EAN-13, UCC / EAN-128, UPC-A, UPC-E, UPCSHIP, UPS 11, MSI, Matrix 2 of 5, PLESSEY, POSTNET, PostBar of 4 states, Austrailian 4-state, FIM, ITF14 , TELEPEN, PLANETA, USPS Intelligent Mail, LOGMARS
  • 2D barcodes: PDF-417, MicroPDF-417, Maxicode, DataMatrix, QR codes, Aztec, GS1 data bar (RSS-14)

FONT, GRAPHICAL SUPPORT PRINTRONIX T4000

  • Graphic formats: PCX, TIFF, BMP, PNG
  • Font technologies: Intellifont, TrueType, Unicode
  • Standard fonts: OCRA, OCRB, Courier, Letter Gothic, CG Times, CG Triumvirate / Bold / Condensed
  • Asian fonts (optional SD card): Simplified Chinese, Japanese and Korean

REMOTE MANAGEMENT SOFTWARE

  • PrintNet Enterprise Auto ID: enterprise-grade remote management solution

OPTIONS AND ACCESSORIES

  • WiFi 802.11 a / b / g / n / ac
  • Bluetooth 4.2 *
  • Cutter
  • Peel / Rewind
  • Andale Asian font cards (SD card)
  • Premium Asian font cards (SD card)
  • QCMC (quick change memory card) (SD card)
  • QCMC (tarjeta de memoria de cambio rápido) (tarjeta SD)
